Product Description
This AC Replaces Old Number 441003.701
Features:
- Vented grille and CT thermostat required
- Efficient Heating At 30 Degree Fahrenheit Temperature Controlled By An LCD Thermostat
- Compact Size With Small Footprint For Use In Tight Spaces
- Washable Micro-Weave Air Filter
- Under The Cabinet Heat Pump For Use In Tent Camper Applications
- Pre-Installed CT Control Board
- Lightweight Construction With Simple Installation
- Limited 2 Year Warranty
- Included: 1 Air conditioner, 1 Warranty card, 1 Registration card, 1 installation manual and 1 operation manual
NOTE: The Dometic 441003AXX1 is not a basement mount or a roof-mount air conditioner. It’s designed as an under-bench or floor-standing (under-cabinet) unit for RVs and campers. This means it’s intended to be installed inside the living space—typically beneath a bench or cabinet—rather than on the roof or in a basement location
A dedicated interior compartment MUST BE provided for the unit installation. This compartment MUST BE OPEN TO THE OUTSIDE AND AIR SEALED TO THE INSIDE. Interior compartment must be at least 20″ deep with an inside cabinet front cutout of 20″ x 14″.
The opening must be 1″ above the mounting surface for the unit.
A 22-3/4″ wide x 15″ high opening through the sidewall or outside panel is required.
Specifications:
- Mount: Under-Bench/Floor-Mounted Unit,
- BTU Level: 10150 BTU
- Ducted System Or Non Ducted System
- With Built-In Single Zone CT Electronic Board
- Color: Black
- Dimensions product depth 20 1/2 "
- Dimensions product height 14 1/2 "
- Dimensions product width 22 "
- Net weight 67 lbs
- Refrigerant Cooling
- AC And Heating
- 120 Volt
- 9 Amp
- 280 CFM (Cubic Feet Per Minute)
- Without Condensate Pump
- Requires CT Single Zone Wall Thermostat
